Single Row Positive Lock 4 Circuits Wire to Board Power Connector,terminla Tin Plated

Single Row Positive Lock 4 Circuits Wire to Board Power Connector,terminla Tin Plated

Single Row Positive Lock 4 Circuits Wire to Board Power Connector,terminla  Tin Plated

Product Details:

Place of Origin: China
Brand Name: JVT
Certification: ISO9001/SGS/UL/ROHS/Reach
Model Number: JVT2039

Payment & Shipping Terms:

Minimum Order Quantity: 1000 PCS
Price: Negotiation
Packaging Details: PE bag packing +outer carton
Delivery Time: 7-10 working days
Payment Terms: T/T or Western Union
Supply Ability: 300000 per month
Contact Now
Detailed Product Description
Pitch: 2.0mm Equivalent: Molex
Applicable Wire: 22 -26 #AWG Poles: 2 - 15

 Single Row Positive Lock 4 Circuits Wire to Board Power Connector Tin Plated


Material Specification :



Phosphor Bronze ,Tin plated


Nylon 66 UL94V-0


Nylon 66 UL94V-0


Brass ,Tin plated


JVT supply 2.00mm Pitch  Wire-to-Board Housing connector , Single Row, Positive Lock, 4 Circuits



Standardized Specification:






Applicable wire


Rating Voltage

250V AC/DC

Rating Current


Withstand voltage

1000V AC/minute

Operating temperature

-25°C to +85°C

Insulation resistance

1000MΩ Min

Contact resistance

30MΩ Max.



Features and Benefits:


Positive inner locks
Audible "click", low insertion force and secure mating

Tuning-fork style contact design
Secure contact, and avoids terminal stubbing

Flat area for pick-and-place
Easy automatic board placement

Reinforced metal solder tabs
Secure PCB retention and solder joint strain relief

Footprint compatibility
Drop-in replacement to various competitive versions

Variable plating options available
Design flexibility and cost-effectiveness


JVT offer a complete range of board to board and board to wire connectors including :pin header ,mini jumpers,female header ,PCB Multipole and housing a wide range of applications including :industrial ,Medical and automotive .

All are offered with small moq's ,the majority being stocked items .


Payment Details:


Payment Terms:T/T or Western Union


Minimum Order:1000 Pieces


Primary Competitive Advantages:

  • Service
  • Country of Origin
  • Experienced Staff
  • Guarantee/Warranty
  • International Approvals
  • Price
  • Prompt Delivery
  • Quality Approvals



Main Export Markets:

  • Asia
  • Australia
  • Central/South America
  • Mid East/Africa
  • North America




Equipment and Service:


10 automated infection molding,20 automated pin-setting and 6 high-precision stamping machines


prefessional and patient pre-service & after-service


professsional sales team & engineering team & techinology team


puntual delivery time and complete packaging process


preferable price and best quality
