2 Pin -20 Pin,Tin-Plated, PCB Wire To Board Connectors Pitch,2.54mm Connector,Black Color

2 Pin -20 Pin,Tin-Plated, PCB Wire To Board Connectors Pitch,2.54mm Connector,Black Color

2 Pin -20 Pin,Tin-Plated, PCB Wire To Board Connectors Pitch,2.54mm Connector,Black Color

Product Details:

Place of Origin: China
Brand Name: JVT
Certification: UL ,RoHS ,REACH
Model Number: JVT 1142

Payment & Shipping Terms:

Minimum Order Quantity: 1000
Price: Negotiation
Packaging Details: Tape&Reel
Delivery Time: 5-7 working days
Payment Terms: T/T, Western Union
Supply Ability: 500000pcs per day
Contact Now
Detailed Product Description
Category: PCB Connectors Wire To Board Poles: 2-20
Pitch: 2.54mm Color: Black
Plating: Tin Flash Material: PBT UL94V-0



2 Pin -20 Pin,Tin-Plated, PCB Wire To Board Connectors Pitch,2.54mm Connector



JVT offer a complete range of board to board and wire to board connectors including :pin header ,mini jumpers,female header ,PCB Multipole and housing a wide range of applications including :industrial ,Medical and automotive .

All are offered with small moq's ,the majority being stocked items .





Drawing :



2 Pin -20 Pin,Tin-Plated, PCB Wire To Board Connectors Pitch,2.54mm Connector,Black Color



2 Pin -20 Pin,Tin-Plated, PCB Wire To Board Connectors Pitch,2.54mm Connector,Black Color





Specification ​:



Pitch 2.54mm
Poles 2-20
Withstand voltage 1000V AC/minute
Contact resistance 20mΩmax
Insulation resistance 1000M Ωmin
Voltage rating 250V AC,DC
Current rating 2.5A,AC,DC
Material PA66/PBT UL 94V-0





Payment Details :

:

Payment Terms:T/T or Western Union



Minimum Order:1000 Pieces





Primary Competitive Advantages :



• Country of Origin

• Packaging

• Small Orders Accepted

• Quality Approvals

• Innovative Service

• Superiority of price



Main Export Markets :

• Asia

• Australia

• Central/South America

• Mid East/Africa/North America
