10 Poles Wire To Board Connector JVT2032 PA Series With Secure Locking Device

10 Poles Wire To Board Connector JVT2032 PA Series With Secure Locking Device

Product Details:

Place of Origin: China
Brand Name: JVT
Certification: ISO9001/SGS/UL/ROHS/Reach
Model Number: JVT2032

Payment & Shipping Terms:

Minimum Order Quantity: 1000 PCS
Price: Negotiation
Packaging Details: PE bag packing +outer carton
Delivery Time: 7-10 working days
Payment Terms: T/T or Western Union
Supply Ability: 300000 per month
Contact Now
Detailed Product Description
Equivalent: JST Pitch: 2.0mm
Feature: Highly Reliable Contact Poles: 2-16
Name: 2 Pin Wire To Board Connector

2.0mm pitch connector with secure locking device ,10 poles ,JVT2032 PA series



Product Profile
Series PA connector
Category Wire to Board Crimp style Connectors
Type Disconnectable type
Crimp style, With secure locking device
Feature With secure locking device


Standardized Specification:


Pitch: 2.0mm

Poles: 2-16

Voltage rating: 250V AC/DC

Current rating: 2.5A AC/DC

Withstand voltage: 1500V AC/minute

Working temperature: -25°C to +85°C

Insulation resistance: 1000MΩ Min

Contact resistance: 20MΩ Max


Specification on Material:



Phosphor Bronze ,Tin plated


PBT UL 94V-0


PA66 UL94V-0


Brass ,Gold plated


10 Poles Wire To Board Connector JVT2032 PA Series With Secure Locking Device


JVT offer a complete range of board to board and board to wire connectors including :pin header ,mini jumpers,female header ,PCB Multipole and housing a wide range of applications including :industrial ,Medical and automotive .

All are offered with small moq's ,the majority being stocked items .


Payment Details:


Payment Terms:T/T or Western Union


Minimum Order:1000 Pieces


Primary Competitive Advantages:

  • Service
  • Country of Origin
  • Experienced Staff
  • Guarantee/Warranty
  • International Approvals
  • Price
  • Prompt Delivery
  • Quality Approvals



Main Export Markets:

  • Asia
  • Australia
  • Central/South America
  • Mid East/Africa
  • North America




Equipment and Service:


10 automated infection molding,20 automated pin-setting and 6 high-precision stamping machines


prefessional and patient pre-service & after-service


professsional sales team & engineering team & techinology team


puntual delivery time and complete packaging process


preferable price and best quality
